ST105D
5 Port Fast Ethernet Switch
- Attached safety lock, more stable connection
- High-quality steel housing, more durable
- 5*10/100 Mbps adaptive ports
- LED: 6 sapphire green LED indicators
- All ports support Auto MDI/MDI-X
- Plug and play without configuration, energy-saving
- Power supply: 5V/800mA
Steel Dumb Switch with
Attached Safety Lock
Attached Safety Lock
10/100M Series:
ST105D·ST108D
ST105D·ST108D
Steel Housing
Attached Safety Lock
Plug and Play
Half/Full Duplex Mode
Wall-mounted Design
Surge Protection
8 Pin of Port
Energy Saving
More Stable!
Attached safety lock design, no need to install, it will keep your network cable fixed stable with the switch.
*Attached safety lock with exclusive patent certification, 100% quality assured.
*Attached safety lock with exclusive patent certification, 100% quality assured.
What problems can the attached safety lock solve?
When modular plugs break or become loose, it will cause network lag, disconnection or other problems. The attached safety lock can effectively solve these problems. In addition, it can also help you organize network cables, making your after-sales troubleshooting easier.
Attached Safety Lock Usage Instructions
First, open the safety lock.
Second, plug in the network cable.
Finally, close the safety lock.
Second, plug in the network cable.
Finally, close the safety lock.
8 Pin of Port
8 pin makes your data transmission faster and more stable.
Steel Housing for Better Heat Dissipation
High-quality steel housing, make better heat dissipation, harder and more durable.
4KV Surge Protection
Using higher-quality components to integrate professional surge protection circuits, it is stable and reliable in thunderstorms, reducing after-sales problems caused by weather.
Plug and Play
Plug and play, no need for any setup.
Specification
Hardware
|
Interface |
5 * 10/100M RJ45 adaptive port |
|
Forwarding rate |
10/100Mbps |
|
LED |
PWR 1-5 RJ45 Port |
|
Standard Protocol |
IEEE802.3,IEEE802.3u ,IEEE802.3x |
|
Operation mode |
Half-duplex, full-duplex Auto-negotiation modes MDI/MDI-X auto-adaptation |
|
Power |
DC 5V/800mA |
|
Forwarding mode |
Store-and-forward |
|
Access mode |
CSMA/CD |
Others
|
Dimensions |
100*65*22.55 mm(L*W*H) |
|
Environment |
Operating Temperature : 0℃ ~ 40℃ Operating Humidity : 10% ~ 90% RH non condensing Storage Temperature : -20℃ ~ 70℃ Storage Humidity : 5% ~ 90% RH non condensing |
