Standard

IEEE802.11n/g/b;
IEEE802.11ac/a;
IEEE802.3/3u/ab;

Signal Rate

2.4GHz Up to 300Mbps
5 GHz UP to 867Mbps

Frequency Range

2.4-2.4835GHz; 5.180-5.825GHZ

Transmit Power

20dBm(MAX)

Data Transfer Rate

802.11ac: 80MHZ(433Mbps) 160MHZ(867Mbps)

802.11n:
40MHz(300Mbps, 270Mbps, 240Mbps, 180Mbps, 120Mbps, 90Mbps, 60Mbps, 30Mbps)
20MHz (144Mbps, 130Mbps, 115Mbps, 86Mbps, 57Mbps, 43Mbps, 28Mbps, 14Mbps) (Auto-Sense)
801.11g: (54Mbps, 48Mbps, 36Mbps, 24Mbps, 18Mbps, 12Mbps, 11Mbps, 9Mbps, 6Mbps)
802.11b:(11Mbps,9Mbps, 6Mbps, 5.5Mbps, 2Mbps, 1Mbps)

Wireless Mode

AP, Multiple AP

Wireless Security

64/128-bit WEP,
WPA-PSK/WPA2-PSK (TKIP/AES),WPA/WPA2
SSID Broadcast Enable/Disable
Wireless MAC Filtering

Standards

IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX,
IEEE 802.3u 1000Base-TX

Interface

1* 10/100/1000M Auto MDI/MDIX RJ45 WAN port
3* 10/100/1000M Auto MDI/MDIX RJ45 LAN port
1* 10/100/1000M Fiber port

LED Indicators

SYS, WPS, 5G, 2.4G, SFP, WAN, LAN1 ~3

Buttons

WPS/Default

Antenna

4 * external 5dBi antenna, omni-directional antennas

Power Supply

DC 12V/1A(Output)

Dimensions (L x W x H )

145 * 155 * 35mm

WAN Type

PPPoE, Static IP, DHCP(Dynamic IP), Bridged, DS-Lite, 6rd

Port Forwarding

Virtual Servers, Port Triggering, UPnP, DMZ

Remote Access

Telnet, TFTP, HTTP, HTTPs, SNMP, SSH, PING, TR069

Access Control

IP/MAC/URL & Domain filtering

VPN Pass-through

PPTP, L2TP

Advanced

SNMP, IPv6, RIP, DLNA, TR069, IPTV, IGMP Snooping,
MLD Proxy & Snooping, DDNS, QOS, DOS, DHCP Relay

Certification

FCC, CE

Environment

Operating Temperature: 0℃~40℃
Storage Temperature: -40℃~70℃
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing

Package Contents

1 * N3F
1 * Quick Install Guide
1 * Power Adapter
1 * Gigabit Cable
