MW5360
4G LTE Router With Detachable 4G Antennas
  • Plug & play, access the internet without any setting.
  • Wide Band for LTE, fit for most ISPs.
  • Muti-access, 4G LTE and Wired access available.
  • Simultaneous 2.4GHz 300Mbps.
  • 2* 5dBi high gain WiFi antennas and 2*5dBi detachable 4G antennas.
  • Easy wireless security setup at a push of the WPS button.
  • Intelligent bandwidth control.
  • Quick setup, with built-in multilingual management page.
Multiple Choices
Vary with Demand
4G LTE Wireless Router
MW5360
Up to 300Mbps
Major ISP SIM Cards Compatible
4 High Gain Antennas
Plug and Play
Transform 4G Signal to Wireless
SIM Cards/WAN Access Available
Outdoor Monitoring
WPS
Plug and Play
Compatible with major ISP cards, just insert SIM cards, you can enjoy WiFi anywhere, and can be realized easily online in one step.
Both Indoor and Outdoor
Meet the requirements of different scenarios.
Best 4G Bandwidth Restoration Rate
Equiped with the powerful chipset and discrete 4G module, The highest download rate can be up to 66M, minimize wastage.
Transform 4G Signal to Wireless and Wired Contection
With 2 LAN ports, MW5360 offers not only WiFi but also wired contection, convenient access to wired devices.
Multiple Internet Access
MW5360 offers both 4G LTE and WAN access, which means you can used it as a router, choose either way.
Super Antennas for 4G and WiFi
Powerful and Stable
The MW5360 has 2 detachable 4G antennas to support long-distance signal reception, and 2 high gain antennas for WiFi, ensure reliable wireless peformance.
Supports up to 32 Devices Simultaneously
The MW5360 can easily make up to 32 devices accessible, such as Loptops, PCs, Smart TVs and IP Cameras.
Meet demands of home using or security monitoring network.
BeeWiFi APP Supported
NX62 supports app management, and with the Beewifi router management tool from netis, you can manage your router on mobile devices. It offers a wide range of settings, making router management simple and convenient.
Specification
Wireless

Standards

IEEE 802.11b/g/n 2.4GHz

Signal Rate

Up to 300Mbps2.4GHz

Frequency Range

2.4-2.4835GHz;5.180-5.825GHZ

Transmit Power

20dBm(MAX)
802.11n:
40MHz(300Mbps, 270Mbps, 240Mbps, 180Mbps, 120Mbps, 90Mbps, 60Mbps, 30Mbps)
20MHz (144Mbps, 130Mbps, 115Mbps, 86Mbps, 57Mbps, 43Mbps, 28Mbps, 14Mbps) (Auto-Sense)
801.11g: (54Mbps, 48Mbps, 36Mbps, 24Mbps, 18Mbps, 12Mbps, 11Mbps, 9Mbps, 6Mbps)
802.11b: (11Mbps,9Mbps, 6Mbps, 5.5Mbps, 2Mbps, 1Mbps)

Wireless Modes

AP/APR, Multi-SSID

Wireless Security

None / WEP / WPA-PSK / WPA2-PSK / WPA2-Mixed/WPS

4G LTE

Band for LTE



FDD-LTE:B1/B3/B5/B8

TDD-LTE: B38/B39/B40/B41

HSPA/UMTS:B1/B5/B8

GSM/GPRS/EDGE:B3/B8

TD-SCDMA:B34/B39

EVDO/CDMA:BC0

Mode



FDD-LTETDD-LTETD-SCDMAHSPA+HSUPA

HSDPAUMTSEVDOEDGEGPRSGSMCDMA1x

Card Speed



FDD-LTE: 150 Mbps DL, 50 Mbps UL

TDD-LTE: 132 Mbps DL, 30 Mbps UL

TD-HSUPA:2.8Mbps DL

TD-HSUPA:2.2Mbps UL

DC-HSPA+:42 Mbps DL

HSPA+:21 Mbps DL

HSUPA:5.76Mbps UL

WCDMA: 384 Kbps DL, 384Kbps UL

CDMA2000 EVDO: 3.1Mbps DL, 1.8Mbps UL

EDGE: 237 Kbps DL, 118Kbps UL

GPRS:85.6 Kbps DL, 85.6 Kbps UL

Hardware

Standards

IEEE 802.11b, IEEE 802.11g, IEEE 802.11n

IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX

Interface

1*10/100Mbps Auto MDI/MDIX RJ45 WAN port
2*10/100Mbps Auto MDI/MDIX RJ45 LAN port
SIM card slot

LED Indicators

Power, LAN All, WiFi/WPS,EWAN, LTE Strong, LTE Middle, LTE Weak

Buttons

Default, WPS

Antenna

2* 5dBi WiFi antennas, 2 SMA detachable 4G antennas

Power Supply

DC 12V/1.0A(Output)

Dimensions

(L x W x H )

182mm*108mm*25mm

WAN Type

WAN: DHCP / Static IP / PPPoE / Russia PPPoE / L2TP / PPTP / 3G&4G

Others

Bandwidth Control, Access Control, IPTV, Virtual Server, DMZ,
VPN Pass-through, Dynamic DNS, Static Routing

Others

Certification

FCC, CE, EAC

Environment

Operating Temperature: 0℃~40℃
Storage Temperature: -40℃~70℃
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing

Package

1* MW5360
1* 12V/1.0A Power Adapter
1* Quick Installation Guide (Multilingual)
