NX62 | AX6000 Wireless Dual Band WiFi6 Router

NX62

AX6000 Wireless Dual Band WiFi6 Router

Dual-Band Wi-Fi 6; Equipped with the latest wireless technology.
Next-Gen 6000Mbps Speeds.
More Devices with Less Lagging: OFDMA and MU-MIMO technology.
2.5G Multi-Gigabit port & USB 3.0 port.
Extensive Coverage: beamforming and eight antennas.
Various WAN connection types in AP Router mode: DHCP, Static IP, PPPoE.
Multiple wireless modes: AP Router, WISP.
Easy setup with the WPS button.
Intelligent bandwidth control.
Easy setup and support App management conveniently.

Overview | Specifications | Download

AX6000

High Speed WiFi6 Router

NX62

WiFi 6

Dual Band AX6000

2GHz

Quad-Core CPU

USB 3.0

Port

4×4 MU-MIMO

2.5G WAN/LAN Port

Lightning-Fast Wired Connections

BeeWiFi

APP Supported

128MB

FLASH

512MB

DDR

WPA3

EasyMesh

Whole-home Coverage

160MHz Bandwidth

Double Throughput

8×Fixed
High-Performance Antennas

WiFi 6

Redefine Speed, Experience Faster WiFi

NX62 boasts dual-band WiFi, with wireless speeds of up to 4804Mbps on the 5GHz band and 1201Mbps on the 2.4GHz band,
offering you a faster and more extensive internet experience.

WiFi 6

Redefine Speed, Experience Faster WiFi

NX62 boasts dual-band WiFi, with wireless speeds of up to 4804Mbps on the 5GHz band and 1201Mbps on the 2.4GHz band,
offering you a faster and more extensive internet experience.

2.5Gbps WAN/LAN Ports, Unstoppable

NX62 is equipped with 3 gigabit ports, 2 2.5G WAN/LAN ports make full use of gigabit speeds from your local ISP. Break through the 1G bottleneck and drive your devices to peak performance. WAN/LAN support gives you remarkable flexibility to tailor both ports to fit your network’s needs.

Boosted WiFi Coverage Throughout Your Home

8×Fixed High-Performance Antennas

Equipped with high-power module (FEM), it can send the powerful WiFi signal directly to users' devices, with multiple antennas working together, it covers larger space and reaches further than before.

Easy Mesh
Flexibly Create Whole Home WiFi with NX62

Using Mesh technology, you can easily and quickly set up a mesh network to achieve seamless whole-house WiFi coverage. It's simple to set up and easy to operate.

BeeWiFi APP Supported

NX62 supports app management, and with the Beewifi router management tool from netis, you can manage your router on mobile devices. It offers a wide range of settings, making router management simple and convenient.

Specification

Wireless

Standards	Wi-Fi 6 IEEE 802.11ax/ac/n/a 5 GHz IEEE 802.11ax/n/b/g 2.4 GHz
Signal Rate	AX6000 5 GHz: 4804 Mbps (802.11ax, HE160) 2.4 GHz: 1148 Mbps (802.11ax)
WiFi Range	4 Bedroom Houses 8× Fixed High-Performance Antennas Multiple antennas form a signal-boosting array to cover more directions and large areas Beamforming Concentrates wireless signal strength towards clients to expand WiFi range High-Power FEM Improves transmission power to strengthen signal coverage 4T4R Multiple streams in the same band strengthen the fault tolerance in transmission
WiFi Capacity	Dual-Band Allocate devices to different bands for optimal performance 4×4 MU-MIMO Simultaneously communicates with multiple MU-MIMO clients OFDMA Simultaneously communicates with multiple Wi-Fi 6 clients Improves network efficiency by limiting excessive occupation DFS Access an extra band to reduce congestion 8 Streams Connect your devices to more bandwidth
Wireless Modes	AP Router Mode, WISP Mode,

Hardware

Processor	2 GHz Quad-Core CPU
DDR/FLASH	512MB/128MB
Interface	1* 2.5G WAN Port 12.5G LAN Port 3 1G LAN Ports 1* USB 3.0 Port
Buttons	Mesh(WPS)、RESET，Rower On/Off
Power	DC 12V/2A(Output)

Software

WiFi Encryption	WEP, WPA-PSK, WPA2-PSK, WPA/WPA2-PSK
Network Security	Access Control, IP & MAC Binding
Guest Network	45GHz Guest Network /42.4GHz Guest Network
Protocols	IPv4, IPv6
WAN Types	DHCP, Static IP, PPPoE
Quality of Service	QoS by Device
Forwarding	Virtual Servers, DMZ, UPnP
IPTV	Bridge, Tag VLAN
DHCP	Address Reservation, DHCP Client List, DHCP Server
Access Control	IP Filtering, MAC Filtering, Domain Filtering, IPv6 Filtering
Dynamic DNS	DynDns, no-ip
IGMP	IGMP Proxy, IGMP Snooping
Others	Bandwidth Control, Multiple SSID, TR069, WOL, ARP List, Static Routing, Port Setting, Remote Access, Backup & Restore

Physical

Dimensions(W×D×H)

267mm * 267mm * 167mm

Package Contents

1* NX62

1* Power Adapter

1* RJ45 Ethernet Cable

1* Quick Installation Guide

Others

System Requirements

Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser Cable Subscription with an internet service provider (for internet access)

Certifications

FCC, CE, RoHS, EAC, UkrSEPRO

Environment

Operating Temperature: 0℃~40℃ ( 32℉ ~104℉ )

Storage Temperature: -40℃~70℃ (-40℉ ~158℉ )

Operating Humidity: 10%~90% non-condensing

Storage Humidity: 5%~90% non-condensing

Test Data

WiFi Transmission Power

2.4G: 22DB

5G: 19.5DB
