Interface

1*2.5G AUTO MDI/MDIX RJ45 WAN ports

1*2.5G AUTO MDI/MDIX RJ45 WAN/LAN ports

2*10/100/100/1000M AUTO MDI/MDIX RJ45 WAN/LAN ports

1*10//100/100/1000M AUTO MDI/MDIX RJ45 LAN ports

1*USB 3.0

LED

PWR, SYS,

Port1-2:2.5Gbps,10/100/1000Mbps,activity

Port3-5:1000Mbps,10/100Mbps,activity

Button

Reset Button

Forwarding rate

10/100/1000Mbps,2.5G

Chip

MT7986A+MT7531A+2×GPY211

FLASH

128MB

Memory

512MB

Power Supply

Built-in 12V/1.5A

Applications

Policy routing

Dynamic domain name

Remote access

Port mapping

Static routing

Standard

IEEE802.3, IEEE802.3u, IEEE802.3z, IEEE802.3x, IEEE802.1x

Network

External network Settings

Intranet Settings

DHCP

DNS

Dynamic domain name

Static routing

Hostname

Interface Settings

Port mapping

uPnP Settings

Switch

AC management

AC Control

AP Setup Control

AP Template setup

AP RF settings

AP Advanced settings

AP Device management

AP Setup upgrade

Remote management

BeeWiFi APP

Setup wizard

Quick Configuration Wizard

Expert Wizard

System

Overview

State

System log

Host monitoring

Real-time monitoring

Historical monitoring

Application statistics

Interface Overview

Group management

IP group

Time group

Port group

Application group

MAC group

Domain name group

Behavior management

One-click control

Firewall rules

URL redirection

URL filtering

DNS filtering

WEB access log

Virtual private network

PPTP Server

PPTP client

L2TP server

L2TP client

IPSEC

Advanced features

Secondary protection routing

Shared decryption

PPPoE relay

Port image

Network wake-up

System management

System Settings

Toolbox

Persistent ping

Join the cloud

Scheduled tasks

Route cipher

Firmware upgrade

Feature library upgrade

Restore the default

Backup/Restore

Dimensions

440*205*45mm

Environment

Operating Temperature : 0℃ ~ 40℃

Operating Humidity : 10% ~ 90% RH non condensing

Storage Temperature : -20℃ ~ 70℃

Storage Humidity : 5% ~ 95% RH non condensing
